Character
- Detecting minute particles of metal

Applicable product
- TABLET & CAPSULE
- Powder


A Drawing

Detecting sensitivity
Sensitivity/Model
NMD440
P925
NMD440
P940
NMD440
P960
NMD440
P980
Fe
0.2mm
0.25mm
0.3mm
0.5mm
SUS304
0.3mm
0.45mm
0.6mm
0.9mm

Specification
Spec/Model
NMD440
P925
NMD440
P940
NMD440
P960
NMD440
P980
Passable
size
Passable width
80mm
80mm
80mm
80mm
Passable height
15mm
30mm
50mm
70mm
Detectioin per min
Max 10,000tablet (depending on the product size)
Power unit
Single AC220V 10% 300VA 50/60Hz
Recommended sorting method

- Drop flap type
